Busch-Jaeger system centre

1246-83300

€266.00*

Prices incl. VAT plus shipping costs

Delivery time approx. 22 - 26 business days

Stk

3% discount for advance payment

Free delivery within Germany

Busch-Jaeger system centre

Supply and control device of the Busch-Welcome® system.
For connection of the indoor and outdoor bus
For connection of an electric door opener (12 V~, 1.6 A or potential-free output 30 V, 3 A).
For switching the light or connecting a light relay (230 V, 3 A).
Adjustable door opener or light switching time.
For up to 65 consumer units.
Nominal voltage: 230 V~, +10 % / -10 %
Output voltage: 28 V
Nominal frequency: 50 Hz / 60 Hz
Nominal power: 42 W
Protection class device: IP 20
Temperature range device: -5 °C - 45 °C
Use high-impedance electric strikes. Nominal resistance min. 20 Ohm.

Busch-Jaeger Elektro GmbH
Freisenbergstraße 2
58513 Lüdenscheid
Deutschland
info.bje@de.abb.com

Width in mm:	216 (12TE)
Height in mm:	90
Depth in mm:	65,0
Weight in kg:	0,2
